How to use the glass double-edge machine?

The double-edge machine is an abbreviation for the glass double-edge straight-edge grinding machine, and its functioning is identical to that of other glass machines. This page mostly covers how to operate the glass bilateral machine from the four perspectives listed below.

glass grinding machines


There must be specific training for bilateral machine operators, regardless of whether the company buys fully automatic, intelligent bilateral grinding equipment. Even if the procedure is simple and easy to master, it is still required to go through training before starting work. The crew must be knowledgeable about the structure of the bilateral machine, its performance, operational safety standards, and repair and maintenance practices. In addition, the operator must wear professional attire, gloves, protective glasses, and other labor protection equipment before beginning work. To avoid accidents and machine damage, non-bilateral machine operators are not permitted to use the equipment.

Machine aspects

1. Before starting the machine, check to see if the switch is loose and if the grinding wheel is worn, and needs to be replaced. Following that, test the water pump to see if the random start, cooling water nozzle location, and so on are correct. Simultaneously, turn on the grinding head motor to check that the grinding head is running normally and that the steering fulfills the processing requirements. Check to see if the tool feed is in the regular position; if not, the original dial value should be restored first. Afterward, modify the bilateral machine's processing settings, such as grinding volume, processing glass thickness, and processing glass width, based on the processing glass specifications and process requirements for that day.

2. Turn on the machine and the control system switch after the first step of inspection. At this point, you need to verify whether the air pressure is up to specification and whether the belt functioning is normal; if there is any anomaly, then promptly shut down the machine and cut off the power to exclude the "defect."

3. Start the water pump and both sides of the motor, inspect the pump's water spraying situation and the internal situation of the grinding head's water tank, and evaluate whether the grinding head motor is operating normally. Pay close attention to the direction of glass transmission and feeding. It is advised that the small grinding machine's air pressure valve be set between 0.2 and 22. After the inspection confirms that the product is correct, a product processing test will be performed, and the processed glass will be mass-produced once the processing technology requirements have been met.

Processing process

1. Place the substitute processed glass flat on the feed frame pallets, and then push it into the feed frame for synchronous transmission into the upper and lower clamping and feeding sections, and carry out rough grinding, fine grinding, and polishing on both sides and take off the glass pieces on the discharge frame after processing in one order.

2. During the processing, the amount of grinding head motor feed can be adjusted appropriately according to the change of the current meter pointer. But it is forbidden to adjust randomly to avoid affecting the effect of the grinding edge.

Final work

After completing the grinding work and unloading all of the processed glass, the bilateral machine should be cleaned from the inside out and subjected to daily maintenance. It should be noted that both the inside and outside residual water must be removed.

Of course, the following is merely a high-level review of the bilateral machine's operating requirements, the precise operating procedures or return to the details of the glass machinery makers' suggestions, and the necessity to configure the technical parameters for glass grinding edge processing.
