L Shape Storage Rack
L shape storage rack have the function of storage and transportation. The rack angle is perfectly at 90 degrees, with the high quality rubber on the bottom, the glass would never slip on it. The L shape shelf can transport glass steady by forklift truck and crane. The rack could be overlaid one by one(ups to 10 pieces) when idle, to share the space and improve the utilization rate of warehouse.
This steel glass rack is made from square steel tube(60×60×3mm), which with good mechanical properties and perfect corrosion resistance. Both of the horizontal and vertical rubber pads, could provide safety for the glass pieces against sliding down in the storage or movement process. The built-in steel plate in the rubber pads, provide long service life with moderate hardness. The rope holes and hanging hook can help to fix the glass on the glass frame safely. On the bottom of the glass racks, there is a weight balance block, help to keep the balance if the glass is placed unbalanced, then no need to worry the fall down of the whole glass rack. Combined with the forklift, the transportation of glass is faster.
The standard L shape glass storage rack have three types, the difference is the width of rack. The glass rack with maximum width could store the glass with total thickness ups to 890mm. Same as other glass sheet storage racks, we could provide you the custom made type according different requirements or designs.
Parameters
Product | Length(mm) | Height(mm) | Width(mm) | Self-weight/piece | Max Storing glass thickness | Rack Quantity in 20GP | Rack Quantity in 40HQ |
L shape storage rack-L1 | 1800 | 1600 | 750 | 95KGS | 540mm | 30 | 86 |
L shape storage rack-L2 | 1800 | 1600 | 950 | 100KGS | 690mm | 26 | 73 |
L shape storage rack-L3 | 1800 | 1600 | 1150 | 115KGS | 890mm | 24 | 68 |
Hot Tags: L Shape Storage Rack, industrial glass storage racks, plate glass storage racks, float glass transport racks, storage for glasses rack, storage for glasses rack, China, manufacturers, suppliers, factory, customized, price
